Mouse Cytokine Array C2000

Mouse Cytokine Array C2000

Item no.	AAM-CYT-2000-4
Manufacturer	Raybiotech
Amount	4 Sample Kit
Quantity options	2 Sample Kit 4 Sample Kit 8 Sample Kit
Category	Oncology Neuroscience Neural Lineage Markers Neuroinflammation Metabolism Diabetes Glucose Homeostasis Cholesterol & Lipid Metabolism Regulation of Appetite Molecular Targets for Neuroscience Aging & Neurological Disorders Neural Signaling Neural Development Neural Adhesion Molecules By Cell Type Blastoma Carcinoma Glioma Hematology Leukemia Lymphoma Myeloma Melanoma Sarcoma Cell Biology Cell Movement Cell Adhesion Obesity Cell Culture Cytokines Cell Status Necrosis Apoptosis Adenocarcinoma Mesothelioma Endocrine Regulation of Lipid Metabolism Senescence Cardiovascular Research Enzymes Heart Failure Myocardial Infarction Fatty Acid Synthesis Arrays By Organ Lung Cancer Bladder Cancer Renal Cancer Lymphatic System Cancer Neuronal Cell Markers Antibody Arrays
Type	Array
Specific against	Mouse (Murine, Mus musculus)
Citations	Takahashi, Kazue, Patience Moyo, and Lorencia Chigweshe. "Efficacy of Recombinant Chimeric Lectins, Consisting of Mannose Binding Lectin and L-ficolin, against Influenza A Viral Infection in Mouse Model Study." Virus Research. ScienceDirect, 26 Dec. 2013. Web.
ECLASS 10.1	32161000
ECLASS 11.0	32161000
UNSPSC	41116126
Similar products	EGF, bFGF, IFN-gamma, IGFBP-5, IL-10, IL-1 beta, IL-6, MMP-2, MMP-3, Osteopontin, TIMP-1, TSLP, VCAM-1, VEGFR1, VEGFR2, HAI-1, SCF, IL-13, IL-4, Resistin, Fractalkine, G-CSF, HGF, IGFBP-2, IL-17, VEGF-A, IL-2, CD40, RAGE, Epiregulin, Prolactin, TACI, IL-21, TWEAK, CD27, E-Cadherin, IGF-1, Axl, RANTES, CD40 Ligand, Endoglin, Granzyme B, M-CSF, MIP-1 alpha, GM-CSF, IL-5, IL-7, IL-11, IL-15, IL-9, Amphiregulin, CXCL16, DKK-1, Epigen, E-Selectin, ICAM-1, IL-3, IL-17E, IL-17F, IL-20, Lymphotactin, MDC, MIG, TARC, TECK, TIMP-2, SDF-1 alpha, LIX, Lungkine, PF-4, Eotaxin-2, 4-1BB, CTACK, IL-17B, CTLA-4, I-TAC, VEGF-D, IL-12 p70, IL-1a, MIP-2, MCP-5, CD36, Galectin-1, Neprilysin, CD30, VEGFR3, Cardiotrophin-1, Chordin, Eotaxin-1, P-Selectin, Thrombopoietin, MIP-1 gamma, BLC, MIP-3 alpha, MIP-3 beta, TNF alpha, MCP1, IGFBP-3, Fas Ligand, MAdCAM-1, Decorin, L-Selectin, IGF-2, Leptin R, Pentraxin 3, 6Ckine, TREM-1, GITR, ALK-1, MFG-E8, TROY, TRANCE, Dtk, JAM-A, CD30 Ligand, TWEAK R, Shh-N, Pro-MMP-9, sTNFRI, IL-6 R, IL-28, IL-2 R alpha, IL-17B R, sTNFRII, IGFBP-6, GITR Ligand, Flt-3 Ligand, CRG-2, Fc gamma RIIB, CD27 Ligand, TCA-3, KC/CXCL1, Leptin/OB, DPPIV/CD26, HGF R, Thymus CK-1, IL-3 Rb, Osteoporotegerin, ACE /CD143, Growth arrest specific 1, Growth arrest specific 6, IL-1 R4/ST2L, IL-1 ra/IL-1F3, IL-12 p 40/p70
Shipping condition	Cool pack
Available
Number of Targets Detected	144
Compatible Sample Types	Cell Culture Supernatants, Plasma, Serum, Tissue Lysates, Cell Lysates
Design Principle	Sandwich-based
Solid Support	Membrane
Kit Components	Mouse Cytokine Antibody Array C2000 Membranes Blocking Buffer Wash Buffer 1 Wash Buffer 2 Biotinylated Detection Antibody Cocktail Streptavidin-Conjugated HRP Detection Buffer C Detection Buffer D Lysis Buffer 8-Well Incubation Tray Plastic Sheets Array Templates Manual
Other Materials Required	Pipettors, pipet tips and other common lab consumables Orbital shaker or oscillating rocker Tissue Paper, blotting paper or chromatography paper Adhesive tape or Saran Wrap Distilled or de-ionized water A chemiluminescent blot documentation system (such as UVPs ChemiDoc-It or EpiChem II Benchtop Darkroom), X-ray Film and a suitable film processor, or another chemiluminescent detection system.
Protocol Outline	Block membranes Incubate with Sample Incubate with Biotinylated Detection Antibody Cocktail Incubate with HRP-Conjugated Streptavidin Incubate with Detection Buffers Image with chemiluminescent imaging system Perform densitometry and analysis
Detection Method	Chemiluminescence
Features	Easy to use No specialized equipment needed Compatible with nearly any liquid sample Proven technology (many publications) Highly sensitive (pg/ml) Sandwich ELISA specificity Higher density than ELISA, Western blot or bead-based multiplex
Result Output	Semi-Quantitative
Short description	RayBio C-Series Mouse Cytokine Antibody Array 2000. A combination of RayBio Mouse Cytokine Antibody Array C3, C4, & C5 Kit. Detects 144 Mouse Cytokines. Suitable for all liquid sample types.
Storage	For best results, store the entire kit frozen at -20C upon arrival. Stored frozen, the kit will be stable for at least 6 months which is the duration of the product warranty period. Once thawed, store array membranes and 1X Blocking Buffer at -20C and all other reagents undiluted at 4C for no more than 3 months.
Targets Detected	4-1BB, 6Ckine, ACE, ALK-1, Amphiregulin, AXL, bFGF, BLC, Cardiotrophin-1, CCL1, CCL11, CCL17, CCL19, CCL2, CCL20, CCL21, CCL22, CCL24, CCL25, CCL27, CCL3, CCL5, CD105, CD106, CD152, CD26, CD27, CD27 Ligand, CD30, CD30 Ligand, CD32b, CD36, CD40, CD40 Ligand, CD54, CD62L, Chordin, CRG-2, CT-1, CTACK, CTLA-4, CX3CL1, CXCL1, CXCL11, CXCL12 alpha, CXCL13, CXCL14, CXCL15, CXCL16, CXCL4, CXCL7, CXCL9, Decorin, DKK-1, DPPIV, Dtk, E-Cadherin, E-Selectin, EGF, Endoglin, Eotaxin-1, Eotaxin-2, Epigen, Epiregulin, Fas Ligand, Fc gamma RIIB, Flt-3 Ligand, Fractalkine, G-CSF, Galectin-1, Gas 1, Gas 6, GITR, GITR Ligand, GM-CSF, Granzyme B, HAI-1, HGF, HGFR, I-309, I-TAC, ICAM-1, IFN-gamma, IFN-lambda, IGF-1, IGF-2, IGFBP-2, IGFBP-3, IGFBP-5, IGFBP-6, IL-1 alpha, IL-1 beta, IL-1 F1, IL-1 F2, IL-1 F3, IL-1 R4, IL-1 Ra, IL-10, IL-11, IL-12 p40/p70, IL-12 p70, IL-13, IL-15, IL-17, IL-17B, IL-17B R, IL-17C, IL-17E, IL-17F, IL-2, IL-2 R alpha, IL-20, IL-21, IL-28, IL-3, IL-3 R beta, IL-4, IL-5, IL-6, IL-6 R, IL-7, IL-9, JAM-A, KC, L-Selectin, Leptin, Leptin R, LIX, Lungkine, Lymphotactin, M-CSF, MAdCAM-1, MCP-1, MCP-5, MDC, MFG-E8, MIG, MIP-1 alpha, MIP-1 gamma, MIP-2, MIP-3 alpha, MIP-3 beta, MMP-2, MMP-3, MPIF-2, Neprilysin, Osteopontin, Osteoprotegerin, P-Selectin, Pentraxin-3, Platelet Factor 4, Pro-MMP-9, Prolactin, RAGE, RANTES, Resistin, SCF, SDF-1 alpha, Shh-N, Sonic Hedgehog N-Terminal, SPP1, SR-B3, ST2, TACI, TARC, TCA-3, TCK-1, TECK, Thrombopoietin, TIMP-1, TIMP-2, TNF alpha, TNFRSF11B, TNFRSF12, TNFRSF13B, TNFRSF18, TNFRSF19, TNFRSF5, TNFRSF7, TNFRSF8, TNFRSF9, TNFSF11, TNFSF12, TNFSF18, TNFSF5, TNFSF6, TNFSF7, TNFSF8, TPO, TRANCE, TREM-1, TROY, TSG-14, TSLP, TWEAK, TWEAK R, VCAM-1, VEGF-A, VEGF-D, VEGFR1, VEGFR2, VEGFR3, XCL1

Note: The presented information and documents (Manual, Product Datasheet, Safety Datasheet and Certificate of Analysis) correspond to our latest update and should serve for orientational purpose only. We do not guarantee the topicality. We would kindly ask you to make a request for specific requirements, if necessary.

All products are intended for research use only (RUO). Not for human, veterinary or therapeutic use.

AAM-CYT-2000-4.pdf

AAM-CYT-2000-4-datasheet.pdf

AAM-CYT-2000-4-safety-datasheet.pdf
